SKU: GTP06350

4.10 Ratio Dana 35 For () | GPTJ35-4.10, REV-TJ-D35-410

Name: 4.10 Ratio Dana 35 For () | GPTJ35-4.10, REV-TJ-D35-410
Brand: Newstar
SKU: GTP06350
Price: 610.50 USD
Availability: InStock

$610.50

Shipping calculated at checkout.

If you need to order multiple parts, give us a call so our sales team can work to combine your order into fewer packages and save you money on shipping! 858-898-1558

Delivery and Shipping

This part typically ships within 1 to 2 business days.

This Differential Ring and Pinion is precision manufactured to OEM gear ratios and tooth geometry. It distributes torque efficiently between axles, maximizing traction and minimizing wear in commercial trucks.

Specifications

Cover Bolt Quantity	10
Differential Carrier Break	3.54 Ratio and Higher Rear (D35-411)
Differential Carrier Break	3.73 Ratio and Higher Front (D30-410TJ)
Differential Model	Dana 30 TJ
Differential Model	Dana 35
Gear Ratio	4.10
Mounting Location	Front and Rear
Pinion Gear Tooth Quantity	10 Front (D30-410TJ)
Pinion Gear Tooth Quantity	9 Rear (D35-411)
Pinion Shaft Diameter	1.376 Inch
Pinion Spline Count	26
Ring Gear Bolt Quantity	10 Front (D30-410TJ)
Ring Gear Bolt Quantity	8 Rear (D35-411)
Ring Gear Material	8620 Steel
Ring Gear Outside Diameter	7.125 Front (D30-410TJ) Inch
Ring Gear Outside Diameter	7.5 Rear (D35-411) Inch
Ring Gear Rotation	Standard
Ring Gear Tooth Quantity	37 Rear (D35-411)
Ring Gear Tooth Quantity	41 Front (D30-410TJ)
Warranty Period	1 Year or 50,000 Miles

Vehicle Applications

Year	Make	Model
1997-2006	Jeep	Wrangler
1997-2006	Jeep	TJ

Interchange / Cross-Reference Numbers

Brand	Part Number
Nitro Gear & Axle	GPTJ35-4.10
Revolution Gear & Axle	REV-TJ-D35-410
