Air Spring Rolling Lobe Rubber with Plastic Piston — 24.49 in Height, 3-Stud Top, PACCAR Cross

Summary: Heavy-duty rolling lobe suspension spring engineered to match OEM PACCAR specifications. Built with durable rubber bellows and a plastic piston, this unit delivers long-lasting performance and restores suspension ride quality under demanding loads.

Fitment

• Application: OEM replacement suspension spring
• Direct OE Cross: PACCAR 03-08716, C81-1011, C81-1013
• Designed for trucks, trailers, and buses requiring 3-stud top plate configuration

Specifications

• Part Number:
• Type: Rolling Lobe Air Spring
• Bellows Material: Rubber (Black), 1 in thickness
• Piston Material: Plastic
• Top Plate Diameter: 9 in, 3 bolt holes
• Bottom Plate Diameter: 8.06 in, 1 bolt hole
• Maximum Height: 24.49 in
• Minimum Height: 7.76 in
• Weight: 15.00 lb

OEM / Cross References

• PACCAR 03-08716
• PACCAR C81-1011
• PACCAR C81-1013

Included

• 1 × Air Spring
• Packaging: Box
• Mounting hardware not included

Notes

• Mounting configuration: Top – 3 studs, Bottom – 1 bolt hole
• Tall-profile rolling lobe with nearly 25 in maximum height
• Plastic piston reduces overall weight while maintaining strength
• Out of stock — check PACCAR cross numbers for alternates
