Freightliner M2 Business 106 Radiator 2008-2013 BHTR6072001
Regular price
$667.66
Unit price
/
Unavailable
Radiator for Freightliner M2 Business 106. Fits years: 2008-2013.
Specifications
| Spec | Value |
|---|---|
| Part Type | Radiator |
| Construction Type | Aluminum |
| Core Width | 30.63" |
| Core Height | 34" |
| Core Thickness | 1.89" |
| Core Material | Aluminum |
| Tank Material | Plastic |
| Flow Type | Down Flow |
| Inlet Diameter | 2" |
| Outlet Diameter | 2" |
| Outlet Location | Bottom Left |
| Inlet Header Width | 2.875" |
| Outlet Header Length | 31.562" |
| Outlet Header Width | 2.875" |
| Engine Oil Cooler | No |
| Transmission Oil Cooler | Yes |
| TOC Fitting Distance | 18" |
| Surge Tank | No |
| Frame Included | No |
| Radiator Cap | Not Needed |
| Shipping Weight | 54.32 lbs |
| Package Size | 37.75" W × 56" L × 7.25" H |
| Shipment Type | LTL |
| Condition | New |
| Manufacturer Type | Aftermarket |
Vehicle Applications
| Year | Make | Model |
|---|---|---|
| 2008-2013 | Freightliner | M2 Business 106 |
OEM / Cross-Reference Numbers
| Part Number |
|---|
| BHTR6072001 |
